Highlight Features

• USB 2.0 interface, support hot-swappable, and is equipped with serial port to support the long-distance data transmission.
• 64Mb super-memory achieves a long time Offline cutting, meanwhile, the data storage can be achieved even blackout.
• New high-speed PIC remote control system, higher speed, lower noise.
• Digital force & speed adjustable, direct and steady.
• Humane design, allows to adjust cutting force and speed while working.
• High-precision "steel barbed" axis, higher accuracy.
• Auto memory of blade force & Speed, adjustable at any time, easy to use.
• Emergency stop & stop to return at any time to monitor the cutting quality, easy to operate.
• Unique red cutting slot make it easier to operate.
• Contour cut feature work with Optical Eye model only.

Models

     No.   Model      Cutting Size   Media Size     Packing Size          Gross Weight

1.   TC631        630mm               710mm          1.04 * 0.46 * 0.36 m        20KG
2.   TC801        800mm               880mm          1.19 * 0.46 * 0.36 m        25KG
3.   TC1061    1040mm             1120mm          1.43 * 0.46 * 0.36 m        32KG
4.   TC1261    1260mm             1340mm          1.68 * 0.46 * 0.36 m        39KG

Specifications

• Drive Motor: Special Motor Control
• Max Cutting Speed: 600 mm/s
• Cutting Force: 10g - 400g
• LCD: With
• Buffer Capacity: 64Mb
• Resolution: 0.025mm/step
• Repeatability: 0.1mm
• Commands Set: HPGL or DMPL
• Interfaces: Serial or USB 2.0
• Positioning Mode: Origin Setup at Random Available
• Copy Function: Up to 99 copies
• Power: < 100W
• Power Requirement: AC 220V / 110V, 50Hz~60Hz
• Windows Driver: Direct Output from CorelDraw
• Environment: Temperature: 0°C - 35°C, 5% - 95% (Non-condensing)

Software option

• Flexi STARTER Liyu Editions 8.6V2 Windows: with Contour Cutting Feature secured by a USB dongle key.

Note: Specifications are subject to change without prior notice.
