Highlight Features

• USB 2.0 interface, support hot-swappable, and is equipped with serial port to support the long-distance data transmission.
• Digital force & speed adjustable, direct and steady.
• Humane design, allows to adjust cutting force and speed while working.
• LED assistant positioning enables easy contour cutting, more simple and convenient to use.
• New high-speed DSP remote control system, the curve cutting is much more smooth.
• High-precision ‘steel barbed’ axis, higher accuracy.
• Dual high-precision DC servo motor, noise-free work.
• High-strength aluminum alloy body, streamlined appearance, sturdiness and durability, beautiful and elegant.
• Unique red cutting slot make it easy to operate.
• Contour cut feature work with Optical Eye model only.

Models

     No.   Model   Cutting Size   Media Size    Packing Size             Gross Weight

1.   HF751       750mm            850mm           1.07 * 0.33 * 0.37 m       20KG
2.   HF901       950mm          1070mm           1.29 * 0.33 * 0.37 m       25KG
3.   HF1201   1250mm         1360mm            1.59 * 0.33 * 0.37 m       39KG

Specifications

• Drive Motor: Dual DC Servo Motor
• Max Cutting Speed: 800 mm/s
• Cutting Force: 10g - 400g
• LCD: With
• Buffer Capacity: 8Mb
• Resolution: 0.025mm/step
• Repeatability: 0.1mm
• Commands Set: HPGL or DMPL
• Interfaces: USB & R232
• Positioning Mode: Origin Setup at Random Available
• Copy Function: Up to 99 copies
• Power: < 180W
• Power Requirement: AC 220V / 110V, 50Hz~60Hz
• Windows Driver: Direct Output from CorelDraw
• Environment: Temperature: 0°C - 35°C, 5% - 95% (Non-condensing)

Software option

• Flexi STARTER Liyu Editions 8.6V2 Windows: with Contour Cutting Feature secured by a USB dongle key.

Note: Specifications are subject to change without prior notice.
