Highlight Features

The PZ Series grand format line is ideal for high-volume production printing in excellent quality with innovative Konica Minolta KM512/14pl print-heads, Max. Resolution up to 1440dpi, a 2mm letter is easy and clear to see.
Designed for high-volume printing and rush jobs, the PZ with 8 heads of dual CMYK produces billboards, banners, backlit, fleet and vehicle graphics, and point of purchase displays at a maximum print speed of up to 120 m²/hr —— Perfect combination of speed and resolution.
THK high-precision linear guider, Panasonic servo motor enables higher carriage speed and lower noise.
2 Grade gear drive system ensures more accurate step and media feeding.
Broadbanding printing and heating platform, plus the powerful cooling fans system quickly dries ink and medias (especially the vehicle sticker) for high-speed applications.
Independent research and developed Liyu own PCBs, guaranteed machine quality and worry-free after sale.

Models

No. Model Description

Specifications

Print Tech: Piezo continuous drop-on demand(DOD)
Print Head: Konica KM512MN
Print Resolution: Max. 720 * 1440 dpi
Image Size: 3.2 Meter
Media Size: 3.29 Meter
Printing Speed: (Up to) Draft Mode: 90m²/h; Poduction Mode: 60m²/h; Quality mode: 22m²/h
Ink Type: (Up to) Solvent : C, M, Y, K, Lc, Lm
Media Type: Banner, Vinyl, Coating Film, Mesh, etc.
Media Transmission: Roll to Roll
Interface: USB 2.0
Auto take-up and feeding system: Equipped
Heating System: Three Sections of pre-heat, heat and post-heat
Ventilation System: Optional
Packing Size: (Up to) 4.57 * 1.60 * 1.00 Meter
Gross Weight: 500 Kg
Power Requirement: 110V / 220V ±10%, >10A, 50 / 60Hz
Environment: Temperature: 20°C - 30°C, Humidity: 40% - 70% RH
Outdoors Durability: 2 Years
