Highlight Features

Modern design, rigid mechanic system.
Konica head, branded linear guider and servo motor enables high quality print.
Optical fiber data transmission, Anti-interference, more stable data transfer.
Separated location of strong and weak current, higher security.
New platform adsorption function, greatly enhanced the reliability of Vinyl printing.
4/8 heads can be upgrade to each other directly without any changes.
Auto positive pressure and head auto cleaning system, greatly reduced the time and process of head maintenance.
Double head filtration, double insure of head lifetime.
Independent Liyu control software with Bi-direction blank-jump and feather printing functions: save your precious time and improve your printing quality.

Models

No. Model Description

Specifications

Print Tech: Piezo continuous drop-on demand(DOD)
Print Head: Konica KM256
Print Resolution: Max. 360 * 1440dpi / 720 * 1080dpi
Print Width: 1.8 Meter / 3.2 Meter
Printing Speed: (Up to) Draft mode: 76m²/h; Production mode: 54m²/h; Quality mode:26m²/h
Ink Type: (Up to) Solvent : C, M, Y, K, Lc, Lm
Media Type: PVC Banner, Vinyl, Coating Film, Mesh and etc.
Media Transmission: Roll to Roll
Interface: USB 2.0
Rip Software: PhotoPrint or ColorPrint
Heating System: Front and back heater equipped
Auto Feeding System: Equipped
Auto Taking System: Optional
Packing Size: (Up to) 4.80 * 0.81 * 1.06 Meter
Gross Weight: 380 Kg
Power Requirement: 110V / 220V ±10%, >10A, 50 / 60Hz
Environment: Temperature: 20°C - 25°C, Humidity: 40% - 70% RH
