Highlight Features

• Printhead Characteristics: Adopt the advanced Japanese Konica UV specialized head, 512 nozzels double staggered, built-in temperature control system, real printing resolution up to 1440dpi.
• Type of Media: Glass, ceramic, aluminum, wood, doors, cardboard, Chevron board, ceiling, MDF, metal lacquer panels, toilet cover, acrylic, plexiglass, etc.
• Mechanic Superiority: Dual lead screw & dual guider broadside scanning mechanical structure, industry-leading machinery precision; Table loading capacity of 100kg/sqm, automatic take-off and landing crossbeam, maximum media thickness up to 100mm; Sub-vacuum absorption table enables the printing on different sizes of media; Auto. detection of media, Auto. detection of Origin, pneumatic medium jack-up system plus rolling bearings enables even a single person can load the large-format media easily.
• Electronic contol Superiority: Independent developed entire control system,classic combination of USB and Optical fiber, LIYU patent software control system, have experienced numerous customers trials, stability is our permanent commitment.
• Pressure & Ink supply control: Closed-loop automatic control, reliable printing quality; pneumatic control components imported from Japan, guaranteed quality; Liyu patent Valve cleaning system, easy to maintain.
• Color options: The machine can be configured as K, C, M, Y / K, C, M, Y, Lc, Lm / K, C, M, Y * 2 and K, C, M, Y + W; Moreover,the machine could spray with white color as bed or cover or spot-color printing.
• Applications: Ad. and Sign industry; Displays and Demo industry; Decoration and glass industry; Leather, textile and offset printing industry, etc.

Models

     No.           Model                      Description

1.         KJ2512-4                   2.5 * 1.2M / 4 heads / 4C
2.         KJ2512-6                   2.5 * 1.2M / 6 heads / 6C
3.         KJ2512-8                   2.5 * 1.2M / 8 heads / 4,6,7C
4.         KJ2518-4                   2.5 * 1.8M / 4 heads / 4C
5.         KJ2518-6                   2.5 * 1.8M / 6 heads / 6C
6.         KJ2518-8                   2.5 * 1.8M / 8 heads / 4,6,7C

Specifications

• Print Tech: Piezo continuous drop-on demand(DOD)
• Print Head: KM512MH
• Media Size: 2500 mm * 1200 mm
• Printing Speed: (Up to) Draft Mode: 33m²/h; Poduction Mode: 23m²/h; Quality mode: 18m²/h
• Print Resolution: Max: 720 dpi / 1440 dpi
• Color: (Up to) C, M, Y, K, LC, LM, W
• Table Pressure: 100 Kg/m²
• Ink Type: UV Curable ink
• Ink Supply System: Auto ink supplying with Minus-Pressure adjustable
• Cleaning System: Auto Flush System
• X/Y-Driver Motor: Dual AC Servo motor
• Media Type: All kinds of Rigid material and Soft media.
• Media Transmission: Sheet to Sheet
• Interface: USB 2.0
• Maximum Media Thickness: 100 mm
• Auto take-up and feeding system: Auto Motor Drive and Spool by Tension Roller
• Feeding System for Sheet Media: Dual Pinch roller feeding
• Packing Size: (Up to) 3.85 * 2.05 * 1.20 Meter
• Gross Weight: 1060 Kg
• Power Requirement: 110V / 220V ±10%, >10A, 50 / 60Hz
• Environment: Temperature: 15°C - 30°C, Humidity: 40% - 80% RH
• Outdoors Durability: 2 Years

Note: Specifications are subject to change without prior notice.
